Home> level meter >> RF admittance level meter >> MK-L2610Continuous RF Admittance Level Transmitter
  • Product number:MC-000446006624
  • Product name:Continuous RF Admittance Level Transmitter
  • Product Type:MK-L2610
  • Product nameplate:SAIC
  • Project Category:level meter >> RF admittance level meter >>
  • Manufacturer:Shanghai Automation Instrumentation Co., Ltd.
  • Sales unit: Shanghai Automation Instrumentation Marketing Center
  • Information download:Click to enter the download page
  • Introduction
  • Specifications
Continuous (anti-adhesion) RF Level Transmitter, the process used to detect all media, from low dielectric constant (such as refined) products to conductive mud, or even viscous dielectric material. Advanced electronic circuit design for the instrument provides a high precision, high stability and anti-jamming capabilities, while self-diagnostic circuitry to ensure the normal operation of the system. Use HARTTM flexible intelligent communication to complete all operations.
Main technology index
Measuring range: 8cm~45m    output signal: 4~20mA or 20~4mA
Power voltage: 115V/230VAC,50/60Hz;5W;24VDC,2W
Environment temperature: -34℃~+66℃
Linear/accuracy: ±0.5%
Temperature stability: ±0.015%/1°F
Separated distance: 30.54m
Shell protection: Heavy, cast aluminum
Explosion-proof: I level:C、D group
Ⅱ level: E、F、G group

MK-L
X
6
10
X
XX
L100
Series number
Electronic circuit
4=smart circuit
3=universal electronic circuit(output  4~20 or 20~4mA)with self-diagnosis
2=general electronic circuit
 (output  4~20mA)
Continuous
Four-wiring
Electronic circuit
R=separated
Power voltage
24Vdc/110vac/220Vac
Probe
