Home> weighing meter >> BLR-42tension load sensor
  • Product number:MC-000502006053
  • Product name:tension load sensor
  • Product Type:BLR-42
  • Product nameplate:SAIC
  • Project Category:weighing meter >>
  • Manufacturer:Shanghai Automation Instrumentation Co., Ltd.
  • Sales unit: Shanghai Automation Instrumentation Marketing Center
  • Information download:Click to enter the download page
  • Introduction
  • Specifications
S-shape
Sealing type
High accuracy and stability
Sensitivity: 1mV/V
Nonlinear: ±0.03%RO
Lag error: ±0.03%RO
     (20~50kg±0.05%RO
Repeatability error: 0.02%RO
                (20~50kg±0.03%RO)
Creep: ±1%RO/30min
Excitation voltage: recommend 10V~12V(AC or DC)
     Max 20V(AC or DC)
Zero output: ±1%RO
Input resistance: 350Ω±3.5Ω
Output resistance: 350Ω±1.75Ω
Conductor: ф9.5 mm, 4 core, 3m cable
Isolated resistance: >2000MΩ
Working temperature : -10~+70℃
                Relative humidity 5%~90%
Temperature zero change: ±0.03%RO/10℃
              (20~50kg±0.05%RO/10℃)
Temperature output change: ±0.03%RO/10℃
Allowed overload capacity: 20%RL
Conductor: 3 m cable
Notes: RO is rated output(excitation voltage=10V)
      RL is rated load(measuring g=9.80665m/s2)
