Home> flow meter >> electromagnetic flowmeter >> T900F Electromagnetic Flow Converter
  • Product number:MC-000024004909
  • Product name:Electromagnetic Flow Converter
  • Product Type:T900F
  • Product nameplate:SAIC
  • Project Category:flow meter >> electromagnetic flowmeter >>
  • Manufacturer:Shanghai Automation Instrumentation Co., Ltd.
  • Sales unit: Shanghai Automation Instrumentation Marketing Center
  • Information download:Click to enter the download page
  • Introduction
  • Specifications
T900F electromagnetic flow converter can be used withφ10～φ3000 M900 electromagnetic flow sensor to form MT900F series electromagnetic flowmeter. it is used to measure volume flow of acid and alkali corrosive media or liquid-solid two-phase medium.
Features
Machine equipped with self-calibration device, user can do regular inspection.
There are many functions for users to choose.
Current output isolation
It can connect with electric counter directly.
Model
Model of converter
Sensor diameter
remark
T900F
T900F/NF
T900F/NF/NB
φ10～450
φ500～1200
φ1300～3000
F is on-site type
F/NF is on-site type

Setting range of full scale：1.000～9.999m/s or 0.500～4.999m/s
Output current：4～20mA DC  load resistance 0～1kΩ
0～10mA DC  load resistance 0～2kΩ
Power supply：220V 50Hz
Power consumption：T900F and T900F/NF ≤20VA NB ≤75VA
enclosure： Cast aluminum， IP65
weight：T900F 9.2kg
 NB900F 8.5kg

T900
Category Type
Current output
Frequency output
Power supply
Optional parts
F
1）0-10 mA DC
1）Per 1m / s velocity output 1kHz
1）220V 50Hz
0）none

1）FU

F/NF
2）4-20 mA DC
2）BA

3）（-10）～（+10）mA DC
2）1kHz full scale output
2）240V 50Hz
3）FU/BA

F/NF/NB
4）（-20）～（+20）mA DC
3）117V 50Hz
4）SMU-1/NR

5）0-20 mA DC
4）110V 50Hz
5）DA

6）special requirement
5）Special Power Supply
6）EZ


7）PU
