CGD series electromagnetic flowmeter is an advance product which uses micro intelligent technology. There are on-site display type and remote display type. It is used to measure volume flow of conductive fluid such as acid, alkali, salt and other corrosive and liquid-solid two-phase fluid.
diameter:DN10~2000
electrode material:1Cr18Ni9Ti, oCr18Ni12Mo2Ti, Hc, Ti, Ta, Pt
lining material:PTFE、Chloroprene rubber, polyurethane rubber
medium:Conductive fluid
measure error: /±0.5%/±1.0% of flow
medium conductivity:>5μS/cm(water >20μS/cm)
Velocity range:0.3~12m/s
Adapter flange:GB9115
Medium temperature:-25℃ to +150℃
Rated pressure:0.6MPa~4.0 MPa
Type of sensor:CGD
Protection level:IP65; IP67; IP68
Type of converter:CGZ-01/CGZ-01A
Output signal:0~10mA or 4~20mA output
communication:RS485
power supply:220VAC,24VDC
explosion-proof mark:Exdm(ib)ⅡBT5~T6
relate equipment:LB910P zenar safety barrier
