  • Product number:MC-000027004796
  • Product name:Glass Rotameter
  • Product Type:LZB、LF
  • Product nameplate:SAIC
  • Project Category:flow meter >> rotary flowmeter >>
  • Manufacturer:Shanghai Automation Instrumentation Co., Ltd.
  • Sales unit: Shanghai Automation Instrumentation Marketing Center
  • Information download:Click to enter the download page
  • Introduction
  • Specifications
Low pressure loss:1.96～2.94kPa
It is applicable to low flow measurement where small throttle device can not be used.
LZB series of the same caliber can be exchanged with the specification conical tube and float glass products.
Simple structure and easy to install
Low price

model
LZB
LF
Working pressure MPa
0.6
0.3
Medium temperature ℃
＜60
＜40
Range ratio
10：1
LF-6-1 10：1 LF-6-2  5：1
Accuracy grade
LZB-15 2.5 LZB-2 1.5 LZB-40 1.5
4.0
Contact medium part material
Chlorinated polyether, or polypropylene
Hard rubber  ABS
Acid-resistant steel 1Cr18Ni9Ti or Aluminum LY11

model
NP  mm
Range L/h
Weight kg
liquid
gas
LZB-15
15
10～100 16～160 25～250 40～400
250～2500 400～4000 600～6000
6
LZB-25
25
40～400 60～600 100～1000
1000～10000 1600～16000 2500～25000
7
LZB-40
40
100～1000 160～1600 250～2500
4000～40000 6000～60000
10
LZB-10
6
1.4～14 3.4～34
35～350 54～540 100～1000
0.5
LF-6-2
6
0.5～2.5 0.9～4.5 1.3～6.5
12～60 20～100 34～170 50～250
0.6

,
