Home> actuator >> accessories >> Z61WH -106 socket welding forged steel gate valve
  • Product number:MC-000456004123
  • Product name:socket welding forged steel gate valve
  • Product Type:Z61WH -106
  • Product nameplate:SAIC
  • Project Category:actuator >> accessories >>
  • Manufacturer:Shanghai Automation Instrumentation Co., Ltd.
  • Sales unit: Shanghai Automation Instrumentation Marketing Center
  • Information download:Click to enter the download page
  • Introduction
  • Specifications
Nominal diameter

d




L




H



W


A


B


C


Material





inch

mm
1/4

6
8
84
134
84
22.2
14.5
9．6
105

304

316

304L


316L

3/8
10
9.5
84
134
84
25.8
18
9．6
1/2
15
9.5
84
134
84
33
22.2
9．6
3/4
20
12.8
90.5
143
95
38
27.7
12．7
1
25
19
114
182
108
48
34.5
12．7
11/2
40
28.5
121
216
120
64
49.1
12．7
2
45
36.5
130
259
152
73
61.1
12．7
,
