Home> pressure meter >> pressure-checking meter >> YJY-60 Pressure Gauge Calibrator
  • Introduction
  • Specifications
The pressure calibrator is used to calibrate pressure gauge and other measure pressure instrument. The pressure can achieve at 6MPa and 60MPa. Footnote with A-type means it is equipped with hand pumps.
the maximum calibrate pressure：0～6MPa（YJY-60A，60） 0～60MPa（YJY-600A，600）
Pressure transmission medium: transformer oil (YJY-60A，60） 20#油（YJY-600A，600）
Hand lift pump pressure：＜1MPa
Connection nut：M20×1.5
weight：17.5kg


,
